| Sensor |
1/3", 4.0 megapixe, CMOS, progressive scan
|
| Lens |
2.8 ~ 12mm, motorized zoom lens
|
| DORI Distance Lens (mm) |
2.8 ~ 12mm
|
| DORI Distance Detect |
63 ~ 270mm
|
| DORI Distance Observe (m) |
25.2 ~ 108mm
|
| DORI Distance Recognize (m) |
12.6 ~ 54m
|
| DORI Distance Identify (m) |
6.3 ~ 27m
|
| Angle of View (H) |
106.9° ~ 28.4°
|
| Angle of View (V) |
55.3° ~ 16.4°
|
| Angle of View (O) |
138.9° ~ 34.9°
|
| Shutter |
Auto/Manual, 1 ~ 1/100000s
|
| Minimum Illumination |
Colour: 0.01Lux (F1.6, AGC ON) 0Lux with IR
|
| Day/Night |
IR-cut filter with auto switch (ICR)
|
| IR Range |
Up to 30m (98ft) IR range
|
| Wavelength |
850nm
|
| Video Compression |
H.264, H.265, MJPEG, Ultra 265
|
| Frame Rate |
Main Stream: 4MP (2592*1520), Max 20fps, Sub Stream:720P (1280*720), Max 20fps, Third Stream: D1 (704*576), Max 20fps
|
| Video Bit Rate |
128 Kbps~16 Mbps
|
| OSD |
Up to 4 OSDs
|
| White Balance |
Auto, Auto2, Fine Tune, Locked, Outdoor, Sodium Lamp
|
| Digital noise reduction |
2D/3D DNR
|
| Edge Storage |
Micro SD, up to 256 GB
|
