JackRapid™ Termination Tool

  • Cuts installation time—easy-to-use handle, seats and cuts all wires at once, saving you up to one minute installation time per jack
  • High-quality, consistent terminations—no more compromised connections and wasted jacks.
  • Simple, one-handed operation with an ergonomically designed handle reduces hand fatigue.
Add to wishlist
Share
Category

    The JackRapid Termination Tool is the industry’s most innovative and time-saving installation tool. JackRapid allows you to terminate jacks eight times faster than traditional impact tools—with accuracy that’s unmatched. The patented jack termination tool seats and terminates all wires simultaneously with one squeeze of an ergonomic handle. The built-in blade cuts off the excess wire after it is seated in the connector, eliminating the need for a secondary trim step. Simple, one-handed operation reduces hand fatigue. With JackRapid, you’ll never punch into the palm of your hand or through drywall again.

    Model JR-LEV-1

    JackRapid termination tool (for Leviton 41106, 41108, 5G108)

    Model JR-LEV-1-H

    JackRapid replacement blade head (for Leviton 41106, 41108, 5G108)

    Model JR-SYS-UNI-1

    JackRapid termination tool (for Systimax MPS100E, C5, M1BH and Uniprise UNJ600/500/300)

    Model JR-SYS-UNI-1-H

    JackRapid replacement blade head (for Systimax MPS100E, C5, M1BH and Uniprise UNJ600/500/300)

    Model JR-LEV-2

    JackRapid termination tool (for Leviton 61110, 5G110, 6110G)

    Model JR-LEV-2-H

    JackRapid replacement blade head (for Leviton 61110, 5G110, 6110G)

    Model JR-SYS-2

    JackRapid termination tool (for Systimax MGS400, MGS500, MFP420, MFP520)

    Model JR-SYS-2-H

    JackRapid replacement blade head (for Systimax MGS400, MGS500, MFP420, MFP520)

    Model JR-ORT-2

    JackRapid termination tool (for Ortronics TJ5E00, TJ600, TJ610)

    Model JR-ORT-2-H

    JackRapid replacement blade head (for Ortronics TJ5E00, TJ600, TJ610)

    Model JR-ADC-2

    JR-ADC-2, JACKRAPID TERMINATION TOOL (FOR ADC C6a CopperTen® UTP RJ45 jack and the C6 TrueNet® KM8 UTP RJ45)

    Model JR-ADC-2-H

    JR-ADC-2-H, JACKRAPID REPLACEMENT BLADE HEAD (FOR ADC C6a CopperTen® UTP RJ45 jack and the C6 TrueNet® KM8 UTP RJ45)

    Model JR-ERGOHANDLE

    JackRapid ergonomic handle

    Model JR-PAN-2

    JackRapid termination tool (for Panduit NK688M, NKP5E88M)

    Model JR-PAN-2-H

    JackRapid replacement blade head (for Panduit NK688M, NKP5E88M)
