TS-664-4G

2.5GbE is a must!
Quad-core for multitasking
Smooth video conversion
Upgrade to dual-port 10GbE
Faster USB transfer
More M.2 NVMe SSDs

Add to wishlist
Share
Category
    CPU Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
    CPU Architecture 64-bit x86
    Graphic Processors Intel® UHD Graphics
    Floating Point Unit Yes
    Encryption Engine  (AES-NI)
    Hardware-accelerated Transcoding Yes
    System Memory 8 GB on board (non-expandable)
    Maximum Memory 8GB
    Flash Memory 4GB (Dual boot OS protection)
    Drive Bay 6 x 3.5-inch SATA 6Gb/s

    The system is shipped without HDD.
    For the HDD compatibility list
    Drive Compatibility 3.5-inch SATA hard disk drives
    2.5-inch SATA solid state drives
    Hot-swappable Yes
    M.2 Slot 2 x M.2 2280 PCIe Gen 3 x1
    SSD Cache Acceleration Support Yes
    2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M/10M)
    5 Gigabit Ethernet Port (5G/2.5G/1G/100M) Optional via PCIe expansion card
    10 Gigabit Ethernet Port Optional via PCIe expansion card
    Wake on LAN (WOL) Yes
    Jumbo Frame Yes
    PCIe Slot 1
    Slot 1: PCIe Gen 3 x2

    Card dimensions for PCIe slot：190 x 68.9x 18.76 mm / 7.48 x 2.71 x 0.74 inches.
    USB 2.0 port 2
    USB 3.2 Gen 2 (10Gbps) Port 2 x Type-A
    IR Sensor  (Optional QNAP RM-IR004 remote control)
    HDMI Output 1, HDMI 2.1 (up to 4096 x 2160 @ 60Hz)
    Form Factor Tower
    LED Indicators Power/Status, LAN, USB, HDD1-6
    Buttons Power, USB copy, Reset
    Dimensions (HxWxD) 171 × 235 × 226 mm
    Weight (Net) 2.9 kg
    Weight (Gross) 4.56 kg
    Operating Temperature 0 ~ 40˚C (32˚F ~ 104˚F)
    Storage Temperature -20 – 70°C (-4°F – 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit 120W adapter, 100-240V
    Power Consumption: HDD Sleep Mode 23.22 W
    Power Consumption: Operating Mode, Typical 44.02 W

    Tested with drives fully populated.
    Fan 2 x 90mm, 12VDC
    System Warning Buzzer
    Kensington Security Slot Yes
    Max. Number of Concurrent Connections (CIFS) – with Max. Memory 1,500
